| Dead-Weight | kg | 550 | 1,668 | 1,750 | 1,981 | 2,500 |
| Max Opening | mm | 1,575 | 2,142 | 2,280 | 2,500 | 2,610 |
| Open Height | mm | 900 | 2.136 | 2,200 | 2,391 | 2,630 |
| Closed Diameter | mm | 600 | 1.250 | 1,300 | 1,612 | 1,720 |
| Closed Height | mm | 1,150 | 2,500 | 2,600 | 2,675 | 2,800 |
| Bucket Capacity | ㎥ | 0 | 1 | |||
| Max Load | kg | 800 | 1,600 | 2,000 | 2,600 | 3,200 |
| Flow Demand | l/m | 50 | 90 | 180 | 220 | 280 |
| Suitable Excavator | kg | 8-11 | 12-17 | 18-25 | 26-35 | 36-50 |
| Reference DWG. |  |
