Overall Length(L) | mm | 553~581 | ||
Overall Height(H) | mm | 371 | ||
Overall Width(W) | mm | 780 | 376~440 | 244 |
Installation Length(L1) | mm | 90~100 | ||
Installation Width(W1) | mm | 100~118 | ||
Application Model | SOLAR015, EC15, VI010-2, AX10U-3, AX15-3 SK09SR, 13SR, A5SR, EX20U-3, EX08, ZX10U-2, ZX17U-2, ZX17U-2, 9NX2, 15NX2 TB016, TB108 | |||
Reference DWG. |  | |||
Attachment | Ordinary positon |  | ||
Back positon |  | |||
